DEYE LB version

Name: Inverter - 3.6KW - Hybrid - Deye
SKU: 71901

Hybrid Inverter ON/OFF GRID

SUN-3.6k-SG01/03LP-1EU

INCLUDING WIFI/PARALLEL KIT

Model	SUN3.6-K-SG05LP-1EU SUN5-K-SG05LP-1EU
Battery Input Data
Battery Type	Lead-acid or Li-Ion
Battery Voltage Range (V)	60~40v
Max. Charging Current (A)	90A 120A
Max. Discharging Current (A)	90A 120A
External Temperature Sensor	Optional
Charging Curve	3 Stages / Equalization
Charging Strategy for Li-Ion Battery	Self-adaption to BMS
PV String Input Data
Max. DC Input Power (W)	4680w 6500w
Rated PV Input Voltage (V)	370v(100v~500v)
Start-up Voltage (V)	150v
MPPT Voltage Range (V)	425-125v
Full Load DC Voltage Range (V)	425-240v
PV Input Current (A)	11A 11A
No. of MPPT trackers	2
No. of strings per MPPT tracker	1 1
AC Output Data
Rated AC Output and UPS Power (W)	3600 5000
Max. AC Output Power (W)	3960 5500
AC Output Rated Current (A)	15.7A 21.7A
Max. AC Current (A)	18A 25A
Max. Continuous AC Passthrought (A)	35A
Peak Power (off grid)	2 time of rated power, 10$
Power Factor	0.8 leading to 0.8 lagging
Output Frequency and Voltage	6./50Hz; 240/230/220Vac(single phase)
Grid Type	Single Phase
DC Injection current (mA)	THD<%3 (Linear load<%1.50
Efficiency
Max. Efficiency	�.60
Euro. Efficiency	�.50
MPPT Efficiency	�.90
Protection
PV Arc Fault Detection	Integrated
PV Input lightning protection	Integrated
anti-islanding protection	Integrated
PV string input reserve polarity protection	Integrated
insulation resistor detection	Integrated
residual current monitoring unit	Integrated
output over current protection	Integrated
output shorted protection	Integrated
surge protection	DC Type II/ AC Type II
